1HDD(T/C) |
||||
|
Model |
JF-ADVR-T7204 |
JF-ADVR-T7208 |
JF-ADVR-T7216 |
|
|
Video |
||||
|
Encode |
4CH*1080P@15fps |
8CH*1080P@12ps |
16CH*1080P@12fps |
|
|
Playback |
4CH*1080P@15fps |
4CH*1080P@12fps |
16CH*1080P@12fps |
|
|
Multi-Mode |
Analog |
4CH*1080P |
8CH*1080P/8CH*1080N |
16CH*1080P/16CH*1080N |
|
Hybrid |
4*1080N(Analog)+4*960P(IP) |
4*1080P(Analog)+4*1080P(IP) |
8CH*1080P(Analog)+8CH*1080P(IP) |
|
|
IP |
16CH*1080P/9CH*1080P/ 16CH*960P/4CH*5M |
8CH*1080P+8CH*960P/ 16CH*960P/4CH*3M /4CH*5M |
8CH*1080P+8CH*960P/ 8CH*3M /4CH*5M |
|
|
Video Compression |
H.264 |
|||
|
Audio |
||||
|
Audio Compression |
G.711A |
|||
|
Interface |
||||
|
Video Input |
4*BNC |
8*BNC |
16*BNC |
|
|
Video Output |
1*VGA,1*HDMI |
|||
|
Audio I/O |
4/1 |
4/1 |
2/1 |
|
|
Alarm I/O |
-- |
|||
|
Ethernet |
1*10/100Mbps Ethernet port, RJ45 port |
|||
|
PTZ Control |
1*RS485, Support for multiple PTZ protocol |
|||
|
USB |
2*USB2.0 |
|||
|
Max HDD |
1×8TB |
|||
|
General |
||||
|
Temperature |
0 ℃ - + 55 ℃ |
|||
|
Humidity |
10% -90% RH |
|||
|
Power |
12V/2A |
|||
|
Consumption |
<15W(Without HDD） |
|||
|
Dimension |
255(L)* 236mm(W)* 44mm(H) |
|||
