1080P@25fps
–VF: Manual Focus
–AF: Motorized Zoom
HD lens:2.8-12mm
Support H.265+/H.265/H.264+/H.264 video compression, multi-level video quality configuration;
Support intelligent video: Tripwire, Intrusion, Missing Object;
Protection level is IP66,IK10(optional);
Supporting WEB, VMS, MYEYE platform;
Support mobile phone monitoring (IOS, Android);
Camera
Model
JF-IPC-BA2321-IR3-VF (AF)
Image Sensor
1/2.9" 1080P CMOS
Min.illumination
0.01Lux@F1.2(Color)/0.001Lux@F1.2(B/W)
Lens
2.8-12mm
Day/Night
IR CUT
Wide Dynamic Range
DWDR
Max.IR Distance
40m
Video Compression
H.265+/H.265/H.264+/H.264
Multi-streaming
Dual-stream
Frame Rate
Intelligent Video
Tripwire, Intrusion, MissingObject
Compatibility
--
Interface
Audio In/Out
1/1
Memory Slot
SD, Max 128G
Alarm In/Out
2/1
General
Ingress Protection
IP66,IK10
Working Temperature
-20℃~+65℃
Material
Metal
Power
DC12V±10%,PoE
JF-IPC-BA2321-IR3-VF (AF)Download
