1HDD |
|||
|
Model |
JF-NVR-T7204-4P |
JF-NVR-T8504-4P |
JF-NVR-T8408L-8P |
|
Video |
|||
|
IP Video Inputs |
4CH*1080P |
4CH*5MP |
8 CH*4MP@20fps |
|
Video Compression |
H.264 |
H.265/H.264 |
H.265/H.264 |
|
Input/Record |
4CH*1080P/ 4CH*720P |
4CH*5MP/ 4CH*4MP@20FPS |
8CH*4MP@20FPS/4CH*5MP |
|
Playback |
2CH*1080P/ 4CH*720P |
2CH*5MP/ 4CH*4MP@20FPS |
4CH*4MP@20FPS/2CH*5MP |
|
Interface |
|||
|
PoE |
4 ports |
4 ports |
8 ports |
|
Display |
1HDMI,1VGA |
||
|
Max HDD |
1×6TB |
||
|
Audio In/Out |
-- |
||
|
Alarm In/Out |
-- |
||
|
USB |
2*USB2.0 |
||
|
General |
|||
|
Temperature |
0 ℃～+55 ℃ |
||
|
Humidity |
10%-90%RH |
||
|
Power |
DC48V |
DC48V |
DC48V |
|
Consumption |
<15W(Without HDD) |
||
|
Dimension |
255(L)* 236mm(W)* 44mm(H) |
||
